Technical data GORDON Roadster

GORDON looks like a veteran at first glance, but the opposite is true. GORDON is a modern car, made from lightweight aluminium alloys and carbon fibre. The car's engine meets the latest emission limits and the entire vehicle passes stringent safety tests.


Basic specification

Engine:FM EP6 FADTX Euro VI

Storagelongitudinally behind the front axle

Number of cylinders4

Stroke volume1 598 ccm

Drilling x stroke77,0 x 85,8 mm

Compression ratior10,2

Maximum power164 kW (223 HP)

 at5 500 1/min

Max torque300 Nm

 at2 250 1/m

Valve distributionDOHC

No. of valves16

Fuel injectionmultipoint electronic direct injection Bosch MG1CS042

SuperchargingExhaust supercharger

CatalystIntegrated TWC/GPF

Engine blockaluminium alloy

Cylinder headaluminium alloy

CoolingClosed system with coolant and electric fan

Alternator14V - 90A

Battery12V- 60Ah

Transmission:Mazda MX 5

ClutchSingle disc clutch with disc spring

Transmissionmechanical, 5-speed fully synchronized

Gear ratios

    1.st speed3.136 : 1

    2.st speed1.888 : 1

    3.st speed1.330 : 1

    4.st speed1.000 : 1

    5.st speed0,814 : 1

    R       3.76 : 1

Permanent transfer4.10 : 1

Driven axlerear



Body / frame:

Bodytwo-seater roadster - monocoque welded from aluminium profiles and sheet metal, front and rear auxiliary steel frame, surface panels made of carbon-fibre reinforced composite, luggage compartment behind the seats

Suspension front and rearadjustable gas-liquid coil spring units

Brakestwo-circuit hydraulic with vacuum booster

 front wheel with internal cooling Wilwood

 RearRemote with internal cooling Wilwood

Wheels#chromed wire 7J x 16“

Tyres205/55 R16 V

Steeringcomb steering with electric power steering

Steering wheel diameter350mm



Size and weight:

Length4070 mm

Width1750 mm

Height1240 mm

Front/rear axle track1460/1450 mm

Wheelbase2700 mm

Standby weightt1 010 kg

Total weight1 220 kg

Fuel tank volume50l



Driving performance:

Acceleration 0 - 100 km/h4,9 sec.

Maximum speed210 km/h
